Description
| Image Sensor | 1280×800 CMOS |
| Memory Flash | ≥15,000 code entries (Code 128, 20 bytes) |
| Illumination | White LED |
| Aiming | 650nm laser diode |
| Depth of Field EAN 13 (13mil) | 35mm-280mm |
| Depth of Field Code 39 (5mil) | 70mm-210mm |
| Depth of Field PDF417 (6.67mil) | 50mm-160mm |
| Depth of Field Data Matrix (10mil) | 40mm-170mm |
| Depth of Field QR (15mil) | 20mm-230mm |
| Minimal Print Contrast | 20% |
| Scan Angle Roll | 360° |
| Scan Angle Pitch | ±55° |
| Scan Angle Skew | ±55° |
| Field of View Horizontal | 48° |
| Field of View Vertical | 28° |
| Scan Modes | Automatic Batch, Manual Batch |
| Motion Tolerance | 50cm/s |
| 1D | All major 1D symbologies, including EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 25, Standard 25, Matrix 25, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey. |
| 2D | All major 2D symbologies, including PDF417, QR Code, Data Matrix, Aztec, Maxicode. |
| Dimensions (mm) | Scanner: 95.5(L)x77.5(W)x172.5(H)mm |
| Weight | 227g |
| Interfaces | RS-232, USB |
| Battery Type | 2200mAh lithium-ion battery |
| Expected Battery Life | ≥12 hours of continuous operation (scan once per 6 seconds) |
| Expected Charge Time | ≤4 hours (with power adapter) |
| Notifications | Beep, LED indicator, vibration |
| Input Voltage | 5VDC±5% |
| Operating Temperature | -20℃ to 50℃ (-4°F to 122°F） |
| Storage Temperature | -40℃ to 70℃ (-40°F to 158°F) |
| Humidity | 5% to 95% (non-condensing) |
| Electro Static Discharge (ESD) | ±15 kV (air discharge), ±8 kV (direct discharge) |
| Drop | Scanner: 1.8m. Cradle: 1.0m |
| IP Rating | IP54 |
| Standard | Cradle, USB Cable |
| Optional | RS232 Cable |
| Configuration Tools | EasySet |
| Hardware | FCC Part15 Class B, CE EMC Class B |
| Standard | 3 years |
